JUNIPER – SRX3K-SPC-1-10-40 Services Processing Card

Juniper SRX3K-SPC-1-10-40 Services Processing Card

Details

Juniper SRX3K-SPC-1-10-40 Services Processing Card

Description

This a high-performance Services Processing Card (SPC) designed for the Juniper SRX3000 Series Services Gateways. It provides the processing power required to run advanced security services such as firewall, IPsec VPN, intrusion detection and prevention (IDP), NAT, and application security. The card contains a dedicated Services Processing Unit (SPU) that handles security inspection and traffic processing, ensuring high throughput and low-latency performance for enterprise and service provider networks.

Designed for demanding security environments, the SRX3K-SPC-1-10-40 intelligently processes traffic received from Network Processing Cards (NPCs) and I/O Cards (IOCs), enabling scalable and efficient security operations. It is commonly deployed in data centers, enterprise edge networks, and service provider infrastructures where performance, reliability, and continuous operation are critical. The module is fully compatible with Juniper SRX1400, SRX3400, and SRX3600 Services Gateways.

Key Features

• Services Processing Card (SPC) for SRX3000 Series
• Dedicated Services Processing Unit (SPU)
• Supports firewall, IPsec VPN, NAT, and IDP services
• High-performance security traffic processing
• Scalable architecture for enterprise deployments
• Optimized for data center and service provider environments
• Supports continuous 24/7 operation
• Low-latency security inspection
• Seamless integration with SRX3000 chassis architecture
• Enterprise-grade reliability and performance

Specifications

• Model: SRX3K-SPC-1-10-40
• Product Type: Services Processing Card (SPC)
• Processor: Single 1 GHz Processor
• Memory: 4 GB
• Services Processing Unit (SPU): 1
• Function: Security Services Processing
• Supported Services: Firewall, IPsec VPN, NAT, IDP
• Compatible Platforms: Juniper SRX1400, SRX3400, SRX3600
• Junos OS Support:
  • SRX3400/SRX3600: Junos OS 9.3 and later
  • SRX1400: Junos OS 10.2 and later
• Throughput Class: 10 Gbps to 40 Gbps Security Processing
• Maximum Power Consumption: 118 Watts
• Hot-Swappable: Yes
• Form Factor: Internal Chassis Module
• Deployment Type: Enterprise, Data Center, Service Provider Networks
• Weight: Approximately 1.7 kg (3.7 lbs)
• Application: Firewall Processing, VPN Services, Intrusion Prevention, Secure Network Traffic Inspection
• Manufacturer: Juniper Networks
